Ergonomics Force Gauges Series E

Series E push / pull force gauges make job task analysis and ergonomics analysis simple and accurate, ideal for workplace design, strength assessment, and ergonomic studies. Series E presents the ergonomist and other professionals with a simple and economical testing solution. 100 lbF, 200 lbF and 500 lbF (500, 2,500, and 5,000 N) capacity force gauges are available, along with a wide range of attachments for various applications.

Select a pre-configured kit, including a gauge, accessories, and carrying case, or select each item individually to suit your needs.



Attachments click and lock into place via innovative Click-Lock™ technology, a rugged anti-rotation locking mechanism. The attachments may be clicked into 90° or 180° orientations. No fastening is required, as with conventional force gauges, thereby reducing the risk of damage to the instrument.


Downloads Force Gauge Specifications Ordering Information - Gauges
Gallery   Ordering Information - Kits
Features   Ordering Information - Individual Accessories

  Video - YouTube   Data Sheet Comparison Chart - Series E vs. Series EK3
  Video User's Guide LabVIEW Serial Write / Read VI

gallery thumbnail gallery thumbnail gallery thumbnail

gallery thumbnail
gallery thumbnail
gallery thumbnail gallery thumbnail

  • Measure real time and peak push and pull forces
  • Three measuring ranges: 100, 200, and 500 lbF (500, 1000, and 2,500 N)
  • Click-LockTM accessory mounting technology
  • USB data output
  • High / low limit indicators, for pass / fail and minimum force testing
  • Averaging mode calculates average force over a period of time
  • 5,000-point data memory - data points may be saved individually or logged continuously at up to 7,000 Hz. Data points may be bulk downloaded to included MESURTM Lite data collection software.
  • Statistical calculations for saved data points

Accuracy: ±0.2% of full scale
Sampling rate:   7,000 Hz
Power:   AC or rechargeable battery. Multi-step low battery indicator is displayed, gauge shuts off automatically when power is too low.
Battery life:   Backlight on: up to 7 hours of continuous use
Backlight off: up to 24 hours of continuous use
Measurement units:   lbF, ozF, gF, kgF, N, kN (depending on model, see below)
USB output:   Configurable up to 115,200 baud.
Safe overload:   200% of full scale (display shows “OVER” at 110% and above)
Weight:   1.7 lb [0.8 kg]
Included items:   Carrying case, universal voltage AC adapter, battery, USB cable, resource CD (USB driver, MESUR™Lite software, MESUR™gauge 90-day trial, and user's guide), NIST-traceable certificate of calibration with data
Warranty:   3 years (see individual statement for further details)

Kit pricing is provided below. The contents of these kits are indicated in the next section.
Model Description US Price
EKE-100-1 Advanced ergonomics kit, 100 lbF / 500 N $1,395.00
EKE-200-1 Advanced ergonomics kit, 200 lbF / 1,000 N $1,395.00
EKE-500-1 Advanced ergonomics kit, 500 lbF / 2,500 N $1,395.00
EKE-100-2 Professional ergonomics kit, 100 lbF / 500 N $1,895.00
EKE-200-2 Professional ergonomics kit, 200 lbF / 1,000 N $1,895.00
EKE-500-2 Professional ergonomics kit, 500 lbF / 2,500 N $1,895.00

All models include 110V AC adapters. Add suffix ‘E’ for euro plug (220V),‘U’ for UK plug (220V), or 'A' for Australian plug (220V).
Example: EKE-100-1E, EKE-200-2U

  Model No. Description Advanced Kit1
Professional Kit1
US Price

Ergonomics force gauge

Force capacity and resolution information is provided in the next section.

E1002 Padded attachment, square   $75.00
E1003 Padded attachment, rectangular $85.00
E1004 Padded attachment, curved $95.00
E1005 Padded attachment, circular   $120.00
E1006 Hook $110.00
E1007 Chain / hook assembly   $100.00
E1008 Single handle grip   $100.00
E1009 Double handle grip $150.00
E1010 Pistol grip   $250.00
E1011 Grip adapter     $50.00
E1012 Looped cable2     $45.00
E1013 Myometer kit3     $275.00
E1000 Carrying case, small   $175.00
E1001 Carrying case, large   $250.00

1. Kits include a force gauge with 110V AC adapter. Add suffix ‘E’ for Euro plug, ‘U’ for UK plug, or ‘A’ for Australian plug. Ex: EKE-100-1E
2. Does not fit into carrying cases.
3. Does not fit into carrying cases. Requires E1006 hook.

  Capacity x Resolution
Model lbF ozF kgF gF N kN US Price
ME-100 100 x 0.05 1600 x 1 50 x 0.02 50000 x 20 500 x 0.2 - $995.00
ME-200 200 x 0.05 3200 x 1 100 x 0.02 - 1000 x 0.2 1 x 0.0002 $995.00
ME-500 500 x 0.1 8000 x 2 250 x 0.2 - 2500 x 0.5 2.5 x 0.0005 $995.00
All models include 110V AC adapters. Add suffix ‘E’ for euro plug (220V),‘U’ for UK plug (220V), or 'A' for Australian plug (220V).
Example: ME-100E, ME-500U
